| Size | Thickness | Weight |
| in. | in. | lb./ft. |
| 6 x 6 | 3/16 | 14.53 |
| 1/4 | 19.02 | |
| 5/16 | 23.34 | |
| 3/8 | 27.48 | |
| 1/2 | 35.24 | |
| 8 x 4 | 3/16 | 14.53 |
| 1/4 | 19.02 | |
| 5/16 | 23.34 | |
| 3/8 | 27.48 | |
| 1/2 | 35.24 | |
| 8 x 6 | 3/16 | 17.08 |
| 1/4 | 22.42 | |
| 5/16 | 27.59 | |
| 3/8 | 32.58 | |
| 1/2 | 42.05 | |
| 8 x 8 | 3/16 | 19.63 |
| 1/4 | 25.82 | |
| 5/16 | 31.84 | |
| 3/8 | 37.69 | |
| 1/2 | 48.85 | |
| 5/8 | 59.32 | |
| 10 x 4 | 3/16 | 17.08 |
| 1/4 | 22.42 | |
| 5/16 | 27.59 | |
| 3/8 | 32.58 | |
| 1/2 | 42.05 | |
| 10 x 6 | 3/16 | 19.63 |
| 1/4 | 25.82 | |
| 5/16 | 31.84 | |
| 3/8 | 37.69 | |
| 1/2 | 48.85 | |
| 10 x 8 | 3/16 | 22.18 |
| 1/4 | 29.23 | |
| 5/16 | 36.1 | |
| 3/8 | 42.79 | |
| 1/2 | 55.66 | |
| 10 x 10 | 3/16 | 24.73 |
| 1/4 | 32.63 | |
| 5/16 | 40.35 | |
| 3/8 | 47.9 | |
| 1/2 | 62.46 | |
| 5/8 | 76.33 | |
| *12 x 4 | 3/16 | 19.63 |
| 1/4 | 25.82 | |
| 5/16 | 31.84 | |
| 3/8 | 37.69 | |
| 12 x 6 | 3/16 | 22.18 |
| 1/4 | 29.23 | |
| 5/16 | 36.1 | |
| 3/8 | 42.79 | |
| 1/2 | 55.66 | |
| 12 x 8 | 3/16 | 24.73 |
| 1/4 | 32.63 | |
| 5/16 | 40.35 | |
| 3/8 | 47.9 | |
| 1/2 | 62.46 | |
| 5/8 | 76.33 | |
| 12 x 12 | 1/4 | 39.43 |
| 5/16 | 48.86 | |
| 3/8 | 58.1 | |
| 1/2 | 76.07 | |
| 5/8 | 93.34 | |
| 14 x 6 | 5/16 | 48.86 |
| 3/8 | 58.1 | |
| 14 x 14 | 5/16 | 57.36 |
| 3/8 | 68.31 | |
| 1/2 | 89.68 | |
| 5/8 | 110.36 | |
| 16 x 8 | 3/16 | 29.84 |
| 5/16 | 48.86 | |
| 1/2 | 76.06 | |
| *16 x 12 | 5/16 | 57.36 |
| 3/8 | 68.31 | |
| 1/2 | 89.68 | |
| 16 x 16 | 5/16 | 65.87 |
| 3/8 | 78.52 | |
| 1/2 | 103.15 | |
| 5/8 | 127.37 |
*Available Upon Request
Presentation: In lengths of 40 ft.
For sizes not included in this table, please ask a sales representative.
High resistance to compression and torsion, making them ideal for structural applications that require great rigidity and load-bearing capacity.
“Accessories or tools made from HSS (High-Speed Steel) offer superior performance compared to those traditionally made from carbon steel. They are primarily characterized by their high hardness at very high temperatures, which allows HSS accessories to cut or drill much faster.”
“It is commonly used in construction, engineering, or architecture applications for columns, beams, trusses, or other structural elements.”
