Hot-rolled steel angles with unequal legs, in ASTM A-36 structural steel.
| Thickness and Dimensions | Weight | |
| in. | ||
| Gauge (k) | Dimension (d x bf) | lb./ft. |
| 3/16 | 3×2 | 3.07 |
| 1/4 | 3×2 | 4.5 |
| 4×3 | 5.8 | |
| 5/16 | 4×3 | 7.2 |
| 3/8 | 6×4 | 12.3 |
| 1/2 | 6×4 | 16.2 |
Weight according to ASTM-A-6, A-36 grade and G50.
For sizes not included in this table, please ask a sales representative.
The unequal steel angle differs from the equal steel angle in its dimensions, particularly due to a different leg height. The leg width is greater on one side than on the other.
“They have two sides of different lengths and are used in applications where greater resistance is needed in one specific direction and less resistance in the other.”
“The use of unequal angle sections is very common in sectors such as metalworking and construction.”
